DC590+ DC Drive Integrator Series 2

Digital DC Drives - 3 to 2000 HP (15A – 2400A)

As part of the full DC drives

product range, the DC590+

further confirms Parker SSD

Drives’ position as the market

leader in DC drive technology.

The DC590+ Integrator Series

2 sees the next step in the

development of DC drive

technology, derived from over 30

years experience in designing DC

drives. With its innovative 32-bit

control architecture, the DC590+

has the flexibility and functionality

to more than meet the requirements

of all applications, from basic motor

installations through to the most

demanding multi-motor systems.

The DC590+ is also available as

a “ready to install” drive package

called the DRV. This is a single

integrated module that includes all

the associated power components

within the package. This innovative

approach radically reduces design

time, panel space, wiring time and

cost. The DRV concept is unique

and comes from the experience

gained from thousands of successful

applications across a diverse range

of industries.

Product Overview

FUNCTIONALITY

POWER

DC512C/514C

DC590+ Integrator Series 2

Systems

Process

Simple

2700 Amps32 Amps12 Amps

Product Overview Chart

DC506/

507/508

Benefitting from the improved

performance of a 32-bit RISC

processor, the DC590+ Integrator

Series 2 delivers enhanced

functionality and increased

flexibility, making it suitable

for use in a wider range of more

complex applications.

• Faster drive response

• Greater control capabilities

• Increased math and logic

function blocks

• Enhanced diagnostic and

programming functionality

• Common programming tools

with other SSD Drives models

Advanced Control Architecture

The DC590+ is easily

integrated into new or

existing systems, offering

improved levels of

performance and productivity.
